Small .pdf files reporting – “The item has been truncated in the index because it exceeds the maximum size”

Recently, I encountered an issue with SharePoint 2013 search crawls where .pdf files smaller than 1 MB were reporting a warning: “The item has been truncated in the index because it exceeds the maximum size”. The default MaxDownLoadSize for documents in SharePoint is 64MB, which was more than enough the handle these relatively small .pdf files.

After I reached out to some co-workers; one had suggested that the error might be a false-positive and the entire document had been crawled. I tested this by first searching for words at the end of the document and no matches were found; this would be expected if it were truncated. Next, I tried searching for some text in the middle of the document and no matches were found either. I thought it must have truncated a lot of text and tried searching for text contained at the very beginning of the document. No results were found! So when the warning said it had truncated the item, it had truncated the whole document.

I decided to test a Microsoft Word document of approximately the same size and found that it did not throw a warning. I then exported that Word document to .pdf and crawled it and surprisingly no warning was thrown. I took a look at the properties of both .pdf files. I found that problem .pdf file was version 1.3 (Acrobat 4.x) and had been generated by Microsoft SQL Server Reporting Services (SSRS), while my test document was version 1.6 (Acrobat 6.x).

Figure 1. PDF Version 1.3 (Acrobat 4.x) generated by SQL Server Reporting Services (SSRS).

Figure 2. PDF Version 1.5 (Acrobat 6.x) generated by Microsoft Word

This got me thinking that problem was version 1.3, so I converted my .pdf to 1.3 and crawled it. I was surprised to find that it did not throw the warning as I expected it too. This would mean that either 1) the culprit was SSRS report generation (not the version 1.3), or 2) there was something about converting a version 1.5 to a version 1.3 that fixed the issue. With this in mind, I preferred to find a centralized solution rather than converting every .pdf document in our site.

I decided to try using the official Adobe IFilter in place of the one that is built-in to SharePoint 2013. In order to leverage the custom IFilter, I did the following:

Add-PSSnapin "Microsoft.SharePoint.PowerShell" -ErrorAction SilentlyContinue
$iFilterPath = "C:\Program Files\Adobe\Adobe PDF iFilter 11 for 64-bit platforms\bin\"
$oldPath=(Get-ItemProperty -Path 'Registry::HKEY_LOCAL_MACHINE\System\CurrentControlSet\Control\Session Manager\Environment' -Name PATH).Path
if(!$oldPath.Contains($ifilterPath))
{
    Write-Host "Adding Environment Path"
    $newPath="$oldPath;$iFilterPath"
    Set-ItemProperty -Path 'Registry::HKEY_LOCAL_MACHINE\System\CurrentControlSet\Control\Session Manager\Environment' -Name PATH –Value $newPath
}

Write-Host "Setting Up Registry entries"
#See: http://www.adobe.com/devnet-docs/acrobatetk/tools/AdminGuide/Acrobat_Reader_IFilter_configuration.pdf
$path = "Registry::HKEY_LOCAL_MACHINE\SOFTWARE\Microsoft\Office Server\15.0\Search\Setup\Filters\.pdf"
if(Test-Path $path) {Remove-Item -Path $path -Recurse}
New-Item $path
New-ItemProperty -Path $path -Name Extension -PropertyType String -Value "pdf"
New-ItemProperty -Path $path -Name FileTypeBucket -PropertyType DWord -Value 1
New-ItemProperty -Path $path -Name MimeTypes -PropertyType String -Value "application/pdf"

$path = "Registry::HKEY_LOCAL_MACHINE\SOFTWARE\Microsoft\Office Server\15.0\Search\Setup\ContentIndexCommon\Filters\Extension\.pdf"
if(Test-Path $path) {Remove-Item -Path $path -Recurse}
New-Item $path
Remove-Item -Path $path\* -Recurse
New-ItemProperty -Path $path -Name "(Default)" -PropertyType MultiString -Value "{E8978DA6-047F-4E3D-9C78-CDBE46041603}"



$ssa = Get-SPEnterpriseSearchServiceApplication
$filter = Get-SPEnterpriseSearchFileFormat -SearchApplication $ssa -Identity pdf
if(!$filter.UseIFilter)
{
    Write-Host "Enabling IFilter for SharePoint"
    Set-SPEnterpriseSearchFileFormatState -SearchApplication $ssa -Identity pdf -UseIFilter $true -Enable $true

    Write-Host "Restarting Search Service"
    $service = Get-SPServiceInstance | ? {$_.TypeName -eq "Search Host Controller Service"}
    $service | Stop-SPServiceInstance -Confirm:$false
    while(-not (($service | Where-Object {$_.Status -eq "Disabled"}).Count -eq $service.Count)){
        write-host -ForegroundColor Yellow $service.Status; sleep 5;
        $service = Get-SPServiceInstance | ? {$_.TypeName -eq "Search Host Controller Service"}
    }
    $service | Start-SPServiceInstance
    Write-Host "Restarting IIS"
    iisreset
}

After executing the script, I performed a full crawl and was pleased to find that all of the .pdf size-related warnings were gone. I performed a search using the same criteria as before from the end, middle, and beginning of document and this time results were returned.

Conclusion

While I am not certain if the cause of this issue is SSRS document generation or legacy .pdf version 1.3 documents, I was able to solve this issue using the official IFilter from Adobe. If someone else encounters this problem, hopefully this will help.

SharePoint 2013 Default KeywordQuery Results Columns

Here is a list of the columns that are returned by default for relevant results of a KeywordQuery:

  • Rank
  • DocId
  • FileType
  • SecondaryFileExtension
  • TitleAuthor
  • Size
  • Path
  • Description
  • EditorOWSUSER
  • LastModifiedTime
  • CollapsingStatus
  • HitHighlightedSummary
  • HitHighlightedProperties
  • FileExtension
  • ViewsLifeTime
  • ParentLink
  • ViewsRecent
  • IsContainer
  • DisplayAuthor
  • docaclmeta
  • ResultTypeIdList
  • PartitionId
  • UrlZone
  • AAMEnabledManagedProperties
  • ResultTypeId
  • RenderTemplateId
  • piSearchResultId

BEWARE! Support Technicians Attempting to Gain Root Access

BEWARE! I have heard of many cases recently where people are receiving phone calls from someone claiming to work for Microsoft and wanting to fix a problem on the computer. DO NOT BELIEVE THESE PEOPLE! First of all, Microsoft will never call you; they charge by the minute for technical support.

I had the opportunity to get on the phone with one of these criminals when they were trying to call a friend and they are trying to gain root access to your machine through a custom remote desktop application. Once they gain access, they will have free reign on your machine, documents, etc.

In the instance when I spoke with them, they tried to convince me there was a problem by having me got to Start > Run > and type eventvwr; which is nothing more than the event viewer but might seem “high tech” to the average user. They had me filter for errors and said the errors were caused by this problem (that they could never tell what the problem was). Then they had me go to Start > Run > and type services.msc (the services panel) and asked if I noticed that some of the services were not running and clamed that they were not running because of this “problem” once again. It is absolutely normal for some services to be stopped on your machine.

They will attempt to impress you and convince you something is wrong. My guess is that they will probably attempt to grab identity information or install some malware they will later attempt to charge you to remove.

Migrating a VMware VM to Azure

This document describes the steps necessary to migrate a VMWare virtual machine (.vmx and accompanying .vmdk) to the Microsoft Azure cloud. More detailed documentation is available from Microsoft: Creating and Uploading a Virtual Hard Disk that Contains the Windows Server Operating System and How to Upload a VHD to Windows Azure.

Get the Azure SDK

Download the Microsoft Azure SDK from https://www.windowsazure.com/en-us/develop/downloads/.

Create a Management Certificate

  1. Open the Visual Studio Command Line Prompt as an Administrator
  2. Execute the following command:
    makecert -sky exchange -r -n “CN=<CertificateName>” -pe -a sha1 -len 2048 -ss My “<CertificateName>.cer”
  3. Browse to C:\Windows\SysWOW64 and locate the .cer that was just created.

Note: If you get an error CryptCertStrToNameW failed => 0x80092023 (-2146885597), delete and retype all of the double-quotes in the command.

Add a Management Certificate

  1. Sign into Windows Management Portal
  2. Click on Preview and then Take me to Previous Portal (Note: this is probably a temporary step while Microsoft spins up its IaaS implementation).
  3. Click on Hosted Services, Storage Accounts & CDN
  4. Click on Management Certificates
  5. Click Add Certificate
  6. Click Browse and browse to the .cer file created in the previous step.

Get Account Login Details

  1. While in the Management Certificates section, select the thumbprint (ex. XXXXXXXXXXXXXXXXXXXXXXXXXXXXXXXXXXXXXXXXX) and copy/paste it somewhere safe
  2. Click on the Subscription that the certificate belongs to and select the Subscription ID (ex. ########-xxxx-xxxx-xxxx-xxxxxxxxxxxx) and copy/paste it somewhere safe

Setting Up Your VMware Image

There are several changes that should be made (if needed) to your VMware image before it is converted and uploaded to Azure.

  1. Remove all snapshots – remove any snapshots that you may have. If you do not want to remove snapshots, create a copy of your .vmdk and create a new VMware image that points to it.
  2. Partition must be IDE – If you have any SCSI Devices, you should convert them to IDE. You may want to use a third party tool to do this such as Acronis.
  3. Uninstall VMware tools- if you have installed the VMWare tools, remove them.
  4. Enable Remote Desktop Access – you will want to enable remote desktop connections and make sure that they are permitted through the firewall (if enabled).
  5. Install the Hyper-V Role
  6. Run SysPrep Browse to %windir%\system32\sysprep and run sysprep.exe Make sure Enter System Out-of Box Experience (OOBE) is selected and Generalized is checked

Convert VM to VHD

VHD (Virtual Hard Disk) is the only format that Windows Azure supports so it will need to be converted if the image is from VMWare Workstation. There are a variety of tools available for converting images; I found that the StarWind Image Converter worked well.

Upload to Azure, Setup & Connect

Once the VM has been converted to VHD format, it is ready to be imported to Azure.

  1. Open the Azure Command Line Prompt
  2. Execute the following commands:

    csupload Set-Connection “SubscriptionId=SubscriptionId;CertificateThumbprint=CertThumbprint;ServiceManagementEndpoint=https://management.core.windows.net”

    Note
    : Use the SubscriptionId and Thumbprint noted earlier

    csupload Add-PersistentVMImage –Destination “<BlobStorageURL>/<YourImagesFolder>/<VHDName>” -Label <VHDName> -LiteralPath <PathToVHDFile> -OS Windows

    Note:
    If you have not created a blob, go to Storage and then New. Once created, select the storage instance to get the BlobStorageURL. You do not have to have an images folder; it will create any path that you enter.

Depending on the size of your image and your upload connection speed, it can take up to several days to upload an image. Once the upload is complete, you can create the VM and connect to it.

  1. Click New (Bottom Left)
  2. Select Virtual Machine then From Gallery
  3. Select My Images
  4. You should now see your image listed. Configure your machine as needed.
  5. Once complete, Azure will begin creating and provisioning your VM.
  6. After your VM has been provisioned, click Connect and save the .rdp file where ever you like
  7. Execute the .rdp file to connect to the VM

Note: My provisioning failed; however, I was still able to connect to the image and it appeared to be fine. I am in the process of researching this issue.

References

Microsoft. (2012). Creating and Uploading a Virtual Hard Disk that Contains the Windows Server Operating System. Retrieved June 19, 2012, from https://www.windowsazure.com/en-us/manage/windows/common-tasks/upload-a-vhd/. Microsoft. (2012). How to Upload a VHD to Windows Azure. Retrieved June 19, 2012, from http://msdn.microsoft.com/en-us/library/windowsazure/gg465385.aspx.

Setting up SharePoint 2010 in Amazon Web Services

I was recently given the task to migrate a SharePoint environment to Amazon Web Services (AWS). With limited exposure to cloud computing, I was trying to figure out what shopping on Amazon had to do with moving a SharePoint environment. After a little bit of research, I learned about the cloud concept of an Infrastructure as a Service (IaaS) and that Amazon has been offering IaaS since 2006 with the introduction of Amazon Web Services.

Note to the Reader

The scenario that this blog post is based on required the complete migration of all servers out of a datacenter into the cloud with no on-premise domain controller (like many of you might encounter). The approach describe in t post might not be the best cloud solution for your situation, be sure to do your homework before choosing a path to the cloud. There are other IaaS providers; or perhaps a Platform as a Service (PaaS) such as Microsoft Azure is more suited for your situation.

What is Amazon Web Services?

Amazon Web Services (AWS) in the simplest of terms is a complete datacenter in the cloud. Traditionally, when a business starts, IT assets are purchased, installed, and maintained at a physical location (on-premise). The amount equipment required to set up a datacenter might include routers, switches, cabling, servers, cooling, power, battery backup, monitors, and much more. AWS can provide virtual equivalents of these assets for a relatively small price, reducing the total cost of ownership for the consumer. If the business or idea does not work out, simply shut down the devices and/or cancel your account.

Key Terms

While many of us are might be familiar with the hardware required to set up a

  • Elastic Computer Cloud (EC2) – EC2 is effectively your virtual server room, providing you access to other resources (ex. virtual machines, virtual private network, etc.)
  • Amazon Machine Image (AMI) – AMI is Amazon’s version of a virtual machine; you may be familiar with virtual machines if you have worked with VMware Workstation, Oracle VirtualBox, etc.
  • Virtual Private Cloud (VPC) – In the simplest of terms, a VPC is your virtual private network. If you have ever set up a home network, you probably know that all of the machines on your network have internal IP addresses (ex. 192.168.X.X or 10.0.X.X) and they all share a static IP to communicate with the rest of the Internet; this is your virtual private network.
  • Simple Storage Service (S3) – S3 is a scalable storage solution that allows you to store and retrieve any amount of data anytime.
  • Elastic Block Storage (EBS) – EBS allows you to create and store volumes (virtual hard drives) that can then be attached to AMI Instances.
  • Elastic IP – Is an IP address that can be allocated from Amazon at any time for a cost. An elastic IP can then be associated to any Instance of an AMI for public access.

Setting up a SharePoint Environment

Creating a VPC

If you plan on having more than one server (such as a 3-tier SharePoint environment), the first thing that you will want to do is set up a VPC; so that you can add your instances to it when you create them.

  1. Navigate to the VPC tab.
  2. Click Create a VPC
  3. Select the VPC that best fits your needs (VPC with a Single Public Subnet will be appropriate for most situations)
  4. Click Continue
  5. Edit your VPC IP CIDR Block and Public Subnet as needed (Defaults should be fine for most situations)
  6. Click Create VPC

Creating Security Groups

There are a variety of ways that security groups can be set up. What I ended up doing was creating one for each server type: Domain Controller (dc-sg), Database (db-sg), and SharePoint (sp-sg). For the dc-sg, db-sg, and sp-sg, I opened all incoming traffic for the private subnet (10.0.0.0/16) and port 3389 from anywhere (0.0.0.0/0). For sp-sg, I also opened incoming port 80 traffic from anywhere (0.0.0.0/0).

To create a security group:

  1. Navigate to the VPC tab
  2. Click Security Groups
  3. Click Create Security Group
  4. Enter Name and Description
  5. Select the VPC that you will adding your servers to
  6. Click Yes, Create

Instances

With your virtual network out of the way, it is time to stand up some servers. Depending on the type of environment that you are standing up, the type of instance and AMI used can vary as well as the price.

Choosing an Instance Type

At the time of this writing, AWS offers 4 standard instances that should be considered:

Name Memory CPU Storage
Small (m1.small) 1.7 GB 1 virtual core 160 GB
Medium (m1.medium) 3.75 GB 1 virtual core 410 GB
Large (m1.large) 7.5 GB 2 virtual cores 850 GB
Extra Large (m1.xlarge) 15 GB 4 virtual cores 1690 GB

View all Instance Types
View Instance Pricing

At the time of this writing, Microsoft minimum hardware requirements are as follows:

Tier Scenario Memory CPU Storage
Domain Controller All 8 GB 4-core 80 GB
Database Small deployment 8 GB 4-core 80 GB
Database Large deployment 16 GB 8-core 80 GB
SharePoint All 8 GB 4-core 80 GB

View Microsoft SharePoint 2010 minimum requirements

So what instance should you use? In my opinion, the answer is, like most answers in development, it depends. While AWS recommends Extra Large instances for all servers and High Memory Quadruple Extra Large (not listed) for the database server, this might necessarily be true for all situations. For example, if you were setting up a development environment, you could probably get away using all Small instances. If your SharePoint environment has relatively small usage, Large instances might work for you. Additionally, you need to consider licensing; for example, you could pay Amazon licensing for SQL Server by using one of their SQL AMIs or you could use a regular AMI and install SQL Server using your licensing. Take the time to know your environment; you might want to read the Amazon Web Services SharePoint whitepaper.

Creating Instances

Once you have decided the type of instance(s) that you plan to use:

  1. Navigate to the EC2 tab
  2. Click Instances
  3. Click Launch Instance
  4. Locate an AMI (ex. Microsoft Windows Server 2008 R2 Base) and click Select
  5. Select the Instance Type
  6. Select the VPC tab and select the VPC that you created previously
  7. Click continue
  8. (Optional) Select Prevent against accidental termination (this will prevent you from accidently deleting your instance)
  9. (Optional) Enter an IP Address (if you want your IP address to be in order like I do)
  10. Click Continue
  11. (Optional) Enter a Name (good way to know which server is which) (note: this is not the computer name, just a name within AWS)
  12. Click Continue
  13. Select or create a Key Pair (these are used to encrypt/decrypt the initial Windows administrator password) (make note of where you store your .pem file)
  14. Select the Security Group that you created previously or create one if needed
  15. Click Continue
  16. Check everything and then click Launch

Connecting to an Instance

At this point, an Instance is created from the AMI and is started. Monitor the State and Status Checks and wait for them to both to be green (running and 2/2 checks passed). This can take several minutes, so be patient. Once ready, we can give the instance an Elastic IP Address.

  1. Navigate to EC2
  2. Click Elastic IPs
  3. Click Allocate New Address
  4. Select VPC
  5. Click Yes, Allocate
  6. Check the box next to the Elastic IP that was just created
  7. Select Associate Address
  8. Select the desired instance
  9. Click Yes, Associate

Now that the instance has a public IP, we are ready to connect:

  1. Navigate to EC2
  2. Click Instances
  3. Check the box next to the desired instance
  4. Select the Instance Actions drop down list
  5. Select Get Windows Admin Password
  6. Open the .pem file that you downloaded when you created your key pair, copy ALL of its contents and paste it into the box labeled Private Key
  7. Click Decrypt Password
  8. Your password will be displayed (copy it, save it, memorize it….whichever you choose)
  9. Select the Instance Actions drop down list
  10. Click Connect
  11. From here, you can either download the RDP file or set one up manually and connect to your instance

Making Software Available

Now that you have your instances available, you might be wondering how you are going to install software such as SQL Server and SharePoint; after all, there is no virtual DVD drive. Like most things in the computer world, there are many ways to anything; I tend to stick to what I consider to be simple. I simply created a semi large volume, attached it to an instance, and copied/pasted in RDP. Alternatively, you could download it from MSDN from the server, setup Internet Explorer Enhanced Security (IEEC), and so on. Either way, I believe that it is a good idea to have this software on a volume somewhere that can be used by all machines (either by file share or dismount/mount). To create a volume and mount it to an instance:

  1. Navigate to EC2
  2. Click on Volumes
  3. Click Create Volume
  4. Enter the Size
  5. Select the Availability Zone that your instances reside in
  6. Do not select a Snapshot
  7. Click Yes, Create
  8. Check the box next to the volume that was just created (it is most likely the only one with a State of available)
  9. Select the …More drop down list
  10. Click Attach Volume
  11. Select the instance that you would live to attach it to
  12. Enter xvdf for the Device
  13. Click Yes, Attach
  14. Connect to the Instance
  15. In Windows, navigate to Administrative Tools > Computer Management > Disk Management
  16. Locate the volume that you just attached (it should be Offline)
  17. Right Click on the volume and select Online
  18. You should now be able to use the drive

References

Amazon Web Services, LLC. (2012). About AWS. Retrieved May 22, 2012, from http://aws.amazon.com/what-is-aws/.

Amazon Web Services, LLC. (2012). Amazon EC2 Instance Types. Retrieved May 23, 2012, from http://aws.amazon.com/ec2/instance-types/.

Cloudiquity. (2012). Difference between S3 and EBS. Retrieved May 23, 2012, from http://www.cloudiquity.com/2009/03/differences-between-s3-and-ebs/.



AWS Disaster Recovery Automation w/ Powershell

Amazon has provided several powerful SDKs for developers to interface with Amazon Web Services (AWS). Anything that can be completed using the AWS console can be accomplished via SDK. In this post, we will examine how .Net developers can leverage the AWS SDK to provide a simple disaster recovery plan for a 3-tier SharePoint environment (domain controller, database server, SharePoint server). This approach could be applied to nearly any environment; for more information, you might want to review the AWS Disaster Recovery Demo.

Setup Amazon Simple Email Service (SES)

The first thing you will want to do is apply for access to SES and setup a verified sender address; this may take several hours.

Get the AWS SDK

Download the AWS SDK for .NET.

Get the scripts

After the SDK has been installed, pick a place to store the scripts (ex. C:\AWS). Next, download the four files below (AWSConfig.ps1, AWSUtilities.ps1, DailySnapshots.ps1, and WeeklySnapshots.ps1) into your AWS directory. Alternatively, ff you hover over the code, the Script Highlighter Plugin will provide the ability to copy/paste, view source, etc. Additionally, create a directory called “Logs” inside of your AWS directory.

AWSConfig.ps1

[Download]

############## C O N F I G ##############

#AWS SDK Path
Add-Type -Path "C:\Program Files (x86)\AWS SDK for .NET\bin\AWSSDK.dll"

#Access Keys
$accessKeyID="XXXXXXXXXXXXXXXXXXXX"
$secretAccessKey="XXXXXXXXXXXXXXXXXXXXXXXXXXXXXXXXXXXXXXXX"
$accountID = "############"

#Regions
#$serviceURL="https://ec2.us-west-1.amazonaws.com"
#$serviceURL="https://ec2.us-west-2.amazonaws.com"
#$serviceURL="https://ec2.us-east-1.amazonaws.com"

#Log
$LOG_PATH="C:\AWS\Logs\"

#Email
$FROM_ADDRESS = "you@example.com"
$ADMIN_ADDRESSES = "you@example.com","you2@example.com.com"

#Expiration
$EXPIRATION_DAYS = 5
$EXPIRATION_WEEKS = 4
$MAX_FUNCTION_RUNTIME = 60 # minutes

#Test
$TEST_URL = "http://example.com"

############## A W S  C L I E N T S ##############
#Global Amazon EC2 Client
$config=New-Object Amazon.EC2.AmazonEC2Config
$config.ServiceURL = $serviceURL
$EC2_CLIENT=[Amazon.AWSClientFactory]::CreateAmazonEC2Client($accessKeyID, $secretAccessKey, $config)

#Global Amazon SES Client
$SES_CLIENT=[Amazon.AWSClientFactory]::CreateAmazonSimpleEmailServiceClient($accessKeyID, $secretAccessKey)



AWSUtilities.ps1

[Download]

############## R E A D M E ##############
#--Variables in ALL CAPS live in AWSConfig.ps1

#Run next line only once; is is required to create source for Windows Event Log
#New-EventLog -Source "AWS PowerShell Utilities" -LogName "Application"

############## G L O B A L ##############
#global variable to hold email message
$global:email = ""

############## U T I L I T Y   F U N C T I O N S ##############

#Description: Returns true if function has been running longer than permitted
#Returns: bool
function IsTimedOut([datetime] $start, [string] $functionName)
{

    $current = new-timespan $start (get-date)

    If($current.Minutes -ge $MAX_FUNCTION_RUNTIME)
    {
        WriteToLogAndEmail "$FunctionName has taken longer than $MAX_FUNCTION_RUNTIME min. Aborting!"
        throw new-object System.Exception "$FunctionName has taken longer than $MAX_FUNCTION_RUNTIME min. Aborting!"
        return $true
    }
    return $false
}
#Description: Adds a tag to an Amazon Web Services Resource
#Returns: n/a
function AddTagToResource([string] $resourceID, [string] $key, [string] $value)
{
    try
    {
        $tag = new-object amazon.EC2.Model.Tag
        $tag.Key=$key
        $tag.Value=$value

        $createTagsRequest = new-object amazon.EC2.Model.CreateTagsRequest
        $createTagsResponse = $EC2_CLIENT.CreateTags($createTagsRequest.WithResourceId($resourceID).WithTag($tag))
        $createTagsResult = $createTagsResponse.CreateTagsResult;
    }
    catch [Exception]
    {
        $function = "AddTagToResource"
        $exception = $_.Exception.ToString()
        WriteToLog "function: $exception" -isException $true
    }
}
#Description: Add carriage return characters for formatting purposes (ex. email)
#Returns: string[]
function FixNewLines([string[]] $text)
{
    $returnText=""
    try
    {
        for($i=0;$i -le $text.Length;$i++)
        {
            $returnText+=$text[$i]+"`r`n"
        }
    }
    catch [Exception]
    {
        $function = "FixNewLines"
        $exception = $_.Exception.ToString()
        WriteToLog "function: $exception" -isException $true
    }

    return $returnText

}
#Description: Returns the current log name by determining the timestamp for the first day of the current week
#Returns: string
function GetLogDate
{
    $dayOfWeek = (get-date).DayOfWeek
    switch($dayOfWeek)
    {
        "Sunday" {$dayOfWeekNumber=0}
        "Monday" {$dayOfWeekNumber=1}
        "Tuesday" {$dayOfWeekNumber=2}
        "Wednesday" {$dayOfWeekNumber=3}
        "Thursday" {$dayOfWeekNumber=4}
        "Friday" {$dayOfWeekNumber=5}
        "Saturday" {$dayOfWeekNumber=6}
    }
    if($dayOfWeekNumber -eq 0)
    {
        $logDate = get-date -f yyyyMMdd
    }
    else
    {
        $logDate = get-date ((get-date).AddDays($dayOfWeekNumber * -1)) -f yyyyMMdd
    }
    $logName = $logDate + ".txt"
    return  $logName
}
#Description: Writes a message to a log file, console
#Returns: n/a
function WriteToLog([string[]] $text, [bool] $isException = $false)
{
    try
    {
        if((Test-Path $LOG_PATH) -eq $false)
        {
            [IO.Directory]::CreateDirectory($LOG_PATH)
        }
        $date = GetLogDate
        $logFilePath = $LOG_PATH + $date + ".txt"
        $currentDatetime = get-date -format G
        add-content -Path $logFilePath -Value "$currentDatetime $text"
        write-host "$datetime $text"
        if($isException)
        {
            write-eventlog -Logname "Application" -EntryType "Information" -EventID "0" -Source "AWS PowerShell Utilities" -Message $text
        }
    }
    catch [Exception]
    {
        $function = "WriteToLog"
        $exception = $_.Exception.ToString()
        WriteToLog "function: $exception" -isException $true
    }
}
#Description: Writes a email variable for later usage
#Returns: n/a
function WriteToEmail([string[]] $text, [bool] $excludeTimeStamp = $false)
{
    try
    {
        if($excludeTimeStamp)
        {
            $global:email += "$text`r`n"
        }
        else
        {
            $datetime = get-date -format G
            $global:email += "$datetime $text`r`n"
        }
    }
    catch [Exception]
    {
        $function = "WriteToEmail"
        $exception = $_.Exception.ToString()
        WriteToLog "function: $exception" -isException $true
    }
}

#Description: Write to log and email
#Returns: n/a
function WriteToLogAndEmail([string[]] $text, [bool] $isException = $false)
{
    WriteToLog $text $isException
    WriteToEmail $text
}
############## E M A I L   F U N C T I O N S ##############

#Description: Sends an email via Amazone Simple Email Service
#Returns: n/a
function SendSesEmail([string] $from, [string[]]$toList, [string]$subject, [string]$body)
{
    try
    {
        # Make an Email Request
        $request = new-object -TypeName Amazon.SimpleEmail.Model.SendEmailRequest

        # "$request | gm" provides a lot of neat things you can do
        $request.Source = $from
        $list = new-object 'System.Collections.Generic.List[string]'
        foreach($address in $toList)
        {
            $list.Add($address)
        }
        $request.Destination = $list
        $subjectObject = new-object -TypeName Amazon.SimpleEmail.Model.Content
        $subjectObject.data = $subject
        $bodyContent = new-object -TypeName Amazon.SimpleEmail.Model.Content
        $bodyContent.data = $body
        $bodyObject = new-object -TypeName Amazon.SimpleEmail.Model.Body
        $bodyObject.text = $bodyContent
        $message = new-object -TypeName Amazon.SimpleEmail.Model.Message
        $message.Subject = $subjectObject
        $message.Body = $bodyObject
        $request.Message = $message

        # Send the message
        $response = $SES_CLIENT.SendEmail($request)
    }
    catch [Exception]
    {
        $function = "SendSesEmail"
        $exception = $_.Exception.ToString()
        WriteToLog "function: $exception" -isException $true
    }

}
#Description: Sends an status email to administrators
#Returns: n/a
function SendStatusEmail([string[]] $toAddress, [string] $successString = "", [string] $subject = "")
{

    try
    {
        if($subject -eq "")
        {
            $subject = $successString + ": $ENVIRONMENT_NAME $ENVIRONMENT_TYPE $BACKUP_TYPE Backup"
        }

        $body = $global:email

        if($toAddress -eq $null -or $toAddress -eq "") { $toAddress = $ADMIN_ADDRESSES }

        SendSesEmail $FROM_ADDRESS $toAddress $subject $body
    }
    catch [Exception]
    {
        $function = "SendStatusEmail"
        $exception = $_.Exception.ToString()
        WriteToLog "function: $exception" -isException $true
    }
}
############## I N S T A N C E   F U N C T I O N S ##############

#Description: Returns an Amazon Web Service Instance object for a given instance Id
#Returns: Instance
function GetInstance([string] $instanceID)
{
    try
    {
        $instancesRequest = new-object amazon.EC2.Model.DescribeInstancesRequest
        $instancesResponse = $EC2_CLIENT.DescribeInstances($instancesRequest.WithInstanceId($instanceID))
        $instancesResult = $instancesResponse.DescribeInstancesResult.Reservation
        return $instancesResult[0].RunningInstance[0]
    }
    catch [Exception]
    {
        $function = "GetInstance"
        $exception = $_.Exception.ToString()
        WriteToLog "function: $exception" -isException $true
        return $null
    }
}
#Description: Returns all Amazon Web Service Instance objects
#Returns: ArrayList<Instance>
function GetAllInstances()
{
    try
    {
        $instancesRequest = new-object amazon.EC2.Model.DescribeInstancesRequest
        $instancesResponse = $EC2_CLIENT.DescribeInstances($instancesRequest)
        $instancesResult = $instancesResponse.DescribeInstancesResult.Reservation

         $allInstances = new-object System.Collections.ArrayList

        foreach($reservation in $instancesResult)
        {
            foreach($instance in $reservation.RunningInstance)
            {
                $allInstances.Add($instance) | out-null
            }
        }

        return $allInstances
    }
    catch [Exception]
    {
        $function = "GetAllInstances"
        $exception = $_.Exception.ToString()
        WriteToLog "function: $exception" -isException $true
        return $null
    }
}
#Description: Returns an ArrayList of all running Amazon Web Service Instance objects that are
#Returns: Instance
function GetRunningInstances()
{
    try
    {

        $allInstances = GetAllInstances
        $runningInstances = new-object System.Collections.ArrayList

        foreach($instance in $allInstances)
        {
            if($instance.InstanceState.Name -eq "running")
            {
                $runningInstances.Add($instance) | out-null
            }
        }

        return $runningInstances
    }
    catch [Exception]
    {
        $function = "GetRunningInstances"
        $exception = $_.Exception.ToString()
        WriteToLog "function: $exception" -isException $true
        return $null
    }
}
#Description: Gets the status of an Amazon Web Service Instance object for a given instance Id
#Returns: string
function GetInstanceStatus([string] $instanceID)
{
    try
    {
        $instance = GetInstance $instanceID
        return $instance.InstanceState.Name
    }
    catch [Exception]
    {
        $function = "GetInstanceStatus"
        $exception = $_.Exception.ToString()
        WriteToLog "function: $exception" -isException $true
        return $null
    }
}
#Description: Gets the name of an Amazon Web Service Instance object for a given instance Id
#Returns: string
function GetInstanceName([string] $instanceID)
{
    try
    {
        $name = ""
        $instance = GetInstance $instanceID
        foreach($tag in $instance.Tag)
        {
            if($tag.Key -eq "Name")
            {
                $name = $tag.Value
            }
        }
        return $name
    }
    catch [Exception]
    {
        $function = "GetInstanceName"
        $exception = $_.Exception.ToString()
        WriteToLog "function: $exception" -isException $true
        return $null
    }
}
#Description: Starts an Amazon Web Service Instance object for a given instance Id
#Returns: n/a
function StartInstance([string] $instanceID)
{
    try
    {
        $instanceStatus = GetInstanceStatus $instanceID
        $name = GetInstanceName $instanceID
        if($instanceStatus -eq "running")
        {
            WriteToLog "Instance $name ($instanceID) Already started"
            WriteToEmail "$name already started"
        }
        else
        {
            #Start instance
            $startReq = new-object amazon.EC2.Model.StartInstancesRequest
            $startReq.InstanceId.Add($instanceID);

            WriteToLog "Instance $name ($instanceID) Starting"
            $startResponse = $EC2_CLIENT.StartInstances($startReq)
            $startResult = $startResponse.StartInstancesResult;

            #Wait for instance to finish starting. Unlike Stop instance,start one at a time (ex. DC, SQL, SP)
            $instancesRequest = new-object amazon.EC2.Model.DescribeInstancesRequest

            $start = get-date

            do{
                #abort if infinite loop or otherwise
                if(IsTimedOut $start) { break }

                start-sleep -s 5
                $instancesResponse = $EC2_CLIENT.DescribeInstances($instancesRequest.WithInstanceId($instanceID))
                $instancesResult = $instancesResponse.DescribeInstancesResult.Reservation
            }
            while($instancesResult[0].RunningInstance[0].InstanceState.Name -ne "running")

            WriteToLog "Instance $name ($instanceID) Started"
            WriteToEmail "$name started"
        }
    }
    catch [Exception]
    {
        $function = "StartInstance"
        $exception = $_.Exception.ToString()
        WriteToLog "function: $exception" -isException $true
    }
}
#Description: Starts one or more Amazon Web Service Instance object for a collection of instance Ids
#Returns: n/a
function StartInstances ([string[]] $instanceIDs)
{
    try
    {
        $start = get-date

        foreach($instanceID in $instanceIDs)
        {
            StartInstance $instanceID
        }

        $end = get-date
        $finish = new-timespan $start $end
        $finishMinutes = $finish.Minutes
        $finishSeconds = $finish.Seconds
        WriteToLog "Start Instances completed in $finishMinutes min $finishSeconds sec"

    }
    catch [Exception]
    {
        $function = "Start Instances"
        $exception = $_.Exception.ToString()
        WriteToLog "function: $exception" -isException $true
    }

}
#Description: Starts all Amazon Web Service Instances
#Returns: n/a
function StartAllInstances()
{
    try
    {
        $instances = GetRunningInstances
        foreach($instance in $instances)
        {
            if($STARTALL_EXCEPTIONS -notcontains $instance.InstanceID)
            {
                StopInstance($instance)
            }
        }
    }
    catch [Exception]
    {
        $function = "StopRunningInstances"
        $exception = $_.Exception.ToString()
        WriteToLog "function: $exception" -isException $true
    }
}
#Description: Stops an Amazon Web Service Instance object for a given instance Id
#Returns: bool - is instance already stopped?
function StopInstance([string] $instanceID)
{
    try
    {
        $instanceStatus = GetInstanceStatus $instanceID
        $name = GetInstanceName $instanceID
        if($instanceStatus -eq "stopped")
        {
            WriteToLog "$name ($instanceID) Already Stopped"
            WriteToLog "$name already stopped"
            return $true
        }
        else
        {
            #Stop instance
            $stopReq = new-object amazon.EC2.Model.StopInstancesRequest
            $stopReq.InstanceId.Add($instanceID);

            WriteToLog "Instance $name ($instanceID) Stopping"
            $stopResponse = $EC2_CLIENT.StopInstances($stopReq)
            $stopResult = $stopResponse.StopInstancesResult;
            return $false
        }
    }
    catch [Exception]
    {
        $function = "StopInstance"
        $exception = $_.Exception.ToString()
        WriteToLog "function: $exception" -isException $true
        return $null
    }
}
#Description: Stops one or more Amazon Web Service Instance object for a collection of instance Ids
#Returns: n/a
function StopInstances([string[]] $instanceIDs)
{
    try
    {
        $statusInstanceIDs = new-object System.Collections.ArrayList($null)
        $statusInstanceIDs.AddRange($instanceIDs)

        #Stop all instances
        foreach($instanceID in $instanceIDs)
        {
            if(StopInstance $instanceID)
            {
                $statusInstanceIDs.Remove($instanceID)
            }
        }
        #Wait for all instances to finish stopping
        $instancesRequest = new-object amazon.EC2.Model.DescribeInstancesRequest

        $start = get-date
        do
        {
            #abort if infinite loop or otherwise
            if(IsTimedOut $start) { break }

            start-sleep -s 5
            foreach($instanceID in $statusInstanceIDs)
            {
                $status = GetInstanceStatus $instanceID
                if($status -eq "stopped")
                {
                    $name = GetInstanceName $instanceID
                    WriteToLog "Instance $name ($instanceID) Stopped"
                    WriteToEmail "$name stopped"
                    $statusInstanceIDs.Remove($instanceID)
                    break
                }
            }
        }
        while($statusInstanceIDs.Count -ne 0)

        $end = get-date
        $finish = new-timespan $start $end
        $finishMinutes = $finish.Minutes
        $finishSeconds = $finish.Seconds
        WriteToLog "Stop Instances completed in $finishMinutes min $finishSeconds sec"
    }
    catch [Exception]
    {
        $function = "StopInstances"
        $exception = $_.Exception.ToString()
        WriteToLog "function: $exception" -isException $true
    }
}
#Description: Stops all Amazon Web Service Instances
#Returns: n/a
function StopAllInstances()
{
    try
    {
        [System.Collections.ArrayList]$instances = GetAllInstances
        foreach($instance in $instances)
        {
            if($STOPALL_EXCEPTIONS -notcontains $instance.InstanceID)
            {
                StopInstance($instance.InstanceID)
            }
        }
    }
    catch [Exception]
    {
        $function = "StopAllInstances"
        $exception = $_.Exception.ToString()
        WriteToLog "function: $exception" -isException $true
    }
}

############## S N A P S H O T   F U N C T I O N S ##############

#Description: Returns a Amazon Web Service Snapshot with a given snapshot Id
#Returns: Snapshot
function GetSnapshot([string] $snapshotID)
{
    try
    {
        $snapshotsRequest = new-object amazon.EC2.Model.DescribeSnapshotsRequest
        $snapshotsResponse = $EC2_CLIENT.DescribeSnapshots($snapshotsRequest.WithSnapshotId($snapshotID))
        $snapshotsResult = $snapshotsResponse.DescribeSnapshotsResult
        return $snapshotsResult.Snapshot[0]
    }
    catch [Exception]
    {
        $function = "GetSnapshot"
        $exception = $_.Exception.ToString()
        WriteToLog "function: $exception" -isException $true
        return $null
    }
}
#Description: Returns all Amazon Web Service Snapshots
#Returns: Snapshot[]
function GetAllSnapshots
{
    try
    {
        $snapshotsRequest = new-object amazon.EC2.Model.DescribeSnapshotsRequest
        $snapshotsResponse = $EC2_CLIENT.DescribeSnapshots($snapshotsRequest.WithOwner($accountID))
        $snapshotsResult = $snapshotsResponse.DescribeSnapshotsResult
        return $snapshotsResult.Snapshot
    }
    catch [Exception]
    {
        $function = "GetAllSnapshots"
        $exception = $_.Exception.ToString()
        WriteToLog "function: $exception" -isException $true
        return $null
    }
}
#Description: Returns the Description for Amazon Web Service Snapshot with a given snapshot Id
#Returns: string - description of snapshot
function GetSnapshotDescription([string] $snapshotID)
{
    try
    {
        $snapshot = GetSnapshot $snapshotID
        return $snapshot.Description
    }
    catch [Exception]
    {
        $function = "GetSnapshotDescription"
        $exception = $_.Exception.ToString()
        WriteToLog "function: $exception" -isException $true
        return $null
    }
}
#Description: Deletes an Amazon Web Service Snapshot with a given snapshot Id
#Returns: n/a
function DeleteSnapshot([string] $snapshotID)
{
    try
    {
        $name = GetSnapshotDescription $snapshotID
        WriteToLog "Snapshot $name ($snapshotID) Deleting"

        $deleteSnapshotRequest = new-object amazon.EC2.Model.DeleteSnapshotRequest
        $deleteSnapshotResponse = $EC2_CLIENT.DeleteSnapshot($deleteSnapshotRequest.WithSnapshotId($snapshotID))
        $deleteSnapshotResult = $deleteSnapshotResponse.DeleteSnapshotResult;

        WriteToLog "Snapshot $name ($snapshotID) Deleted"
        WriteToEmail "Snapshot Deleted: $name"

    }
    catch [Exception]
    {
        $function = "DeleteSnapshot"
        $exception = $_.Exception.ToString()
        WriteToLog "function: $exception" -isException $true
    }

}

#Description: Creates an Amazon Web Service Snapshot for a given instance Id
#Returns: string - newly created snapshotID
function CreateSnapshotForInstance([string] $volumeID, [string] $instanceID)
{
    try
    {
        #Generate meaningful description for snapshot
        $date = get-date -format yyyyMMddhhmmss
        $name = GetInstanceName $instanceID
        $description = "{0} {1} {2}" -f $name, $BACKUP_TYPE, $date

        WriteToLog "Instance $name ($instanceID) Creating Snapshot"

        $createSnapshotRequest = new-object amazon.EC2.Model.CreateSnapshotRequest
        $createSnapshotResponse = $EC2_CLIENT.CreateSnapshot($createSnapshotRequest.WithVolumeId($volumeID).WithDescription($description))
        $createSnapshotResult = $createSnapshotResponse.CreateSnapshotResult;

        WriteToLog "Snapshot $description Created for $name ($instanceID)"
        WriteToEmail "$name snapshot successful"
        return $createSnapshotResult.Snapshot.SnapshotId
    }
    catch [Exception]
    {
        $function = "CreateSnapshotForInstance"
        $exception = $_.Exception.ToString()
        WriteToEmail "$name snapshot failed, Exception:"
        WriteToLogAndEmail "function: $exception" -isException $true
        return $null
    }
}
#Description: Creates Amazon Web Service Snapshots for a collection of instance Ids
#Parameters: $instanceIDs string[]
#Returns: n/a
function CreateSnapshotsForInstances([string[]] $instanceIDs)
{
    try
    {
        if($InstanceIDs -ne $null)
        {
            $volumesRequest = new-object amazon.EC2.Model.DescribeVolumesRequest
            $volumesResponse = $EC2_CLIENT.DescribeVolumes($volumesRequest)
            $volumesResult = $volumesResponse.DescribeVolumesResult
            foreach($volume in $volumesResult.Volume)
            {

                if($InstanceIDs -contains $volume.Attachment[0].InstanceId)
                {
                    #Create the snapshot
                    $snapshotId = CreateSnapshotForInstance $volume.VolumeId $volume.Attachment[0].InstanceId

                    #Wait for snapshot creation to complete
                    $snapshotsRequest = new-object amazon.EC2.Model.DescribeSnapshotsRequest

                    $start = get-date
                    do
                    {
                        #abort if infinite loop or otherwise
                        if(IsTimedOut $Start) { break }

                        start-sleep -s 5
                        $snapshotsResponse = $EC2_CLIENT.DescribeSnapshots($snapshotsRequest.WithSnapshotId($snapshotId))
                        $snapshotsResult = $snapshotsResponse.DescribeSnapshotsResult
                    }
                    while($snapshotsResult.Snapshot[0].Status -ne "completed")

                }
            }
        }
        else
        {
            WriteToLogAndEmail "Backup failed; no InstanceIDs to process"
        }
    }
    catch [Exception]
    {
        $function = "CreateSnapshotForInstances"
        $exception = $_.Exception.ToString()
        WriteToLogAndEmail "function: $exception" -isException $true
    }
}
#Description: Returns true if passed date is before the current date minus $EXPIRATION_DAYS value
#Returns: bool
function IsDailySnapshotExpired([datetime] $backupDate)
{
    try
    {
        $expireDate = (get-date).AddDays($EXPIRATION_DAYS*-1)
        return ($backupDate) -lt ($expireDate)
    }
    catch [Exception]
    {
        $function = "IsDailySnapshotExpired"
        $exception = $_.Exception.ToString()
        WriteToLog "function: $exception" -isException $true
        return false
    }
}

#Description: Returns true if passed date is before the current date minus $EXPIRATION_WEEKS value
#Parameters: $backupDate datetime
#Returns: bool
function IsWeeklySnapshotExpired([datetime] $backupDate)
{
    try
    {
        $expireDate = (get-date).AddDays(($EXPIRATION_WEEKS * 7) * -1)
        return ($backupDate) -lt ($expireDate)
    }
    catch [Exception]
    {
        $function = "IsWeeklySnapshotExpired"
        $exception = $_.Exception.ToString()
        WriteToLog "function: $exception" -isException $true
        return false
    }
}
#Description: Deleted old daily snapshots
#Parameters: n/a
#Returns: n/a
function CleanupDailySnapshots
{
    try
    {
        WriteToLog "Cleaning up daily snapshots"
        $deleteCount = 0

        $snapshots = GetAllSnapshots
        foreach($snapshot in $snapshots)
        {
            $description = $snapshot.Description
            $snapshotID = $snapshot.SnapshotId
            if($snapshot.Description.Contains("Daily"))
            {
                $backupDateTime = get-date $snapshot.StartTime
                $expired = IsDailySnapshotExpired $backupDateTime
                if($expired)
                {
                    DeleteSnapshot $snapshot.SnapshotId
                    $deleteCount ++
                    WriteToLog "$description ($snapshotID) Expired"
                }

            }
        }
        WriteToLogAndEmail "$deleteCount daily snapshots deleted"
    }
    catch [Exception]
    {
        $function = "CleanupWeeklySnapshots"
        $exception = $_.Exception.ToString()
        WriteToLogAndEmail "function: $exception" -isException $true
        return false
    }
}
#Description: Deleted old weekly snapshots
#Parameters: n/a
#Returns: n/a
function CleanupWeeklySnapshots
{
    try
    {
        WriteToLog "Cleaning up weekly snapshots"
        $deleteCount = 0

        $snapshots = GetAllSnapshots
        foreach($snapshot in $snapshots)
        {
            $description = $snapshot.Description
            $snapshotID = $snapshot.SnapshotId
            if($snapshot.Description.Contains("Weekly"))
            {
                $backupDateTime = get-date $snapshot.StartTime
                $expired = IsWeeklySnapshotExpired $backupDateTime
                if($expired)
                {
                    DeleteSnapshot $snapshot.SnapshotId
                    $deleteCount ++
                    WriteToLog "$description ($snapshotID) Expired"
                }

            }
        }
        WriteToLogAndEmail "$deleteCount weekly snapshots deleted"
    }
    catch [Exception]
    {
        $function = "CleanupDailySnapshots"
        $exception = $_.Exception.ToString()
        WriteToLogAndEmail "function: $exception" -isException $true
        return false
    }
}



DailySnapshot.ps1

[Download]


############## C O N F I G ##############
."C:\AWS\AWSConfig.ps1"

#Environment
$ENVIRONMENT_NAME = "My Environment"
$ENVIRONMENT_TYPE = "Development"
$BACKUP_TYPE = "Daily"
$stagingInstanceIDs="i-xxxxxxxx","i-xxxxxxxx","i-xxxxxxxx"

############## F U N C T I O N S ##############
."C:\AWS\AWSUtilities.ps1"

############## M A I N ##############

try
{
    $start = Get-Date
    WriteToLogAndEmail "$ENVIRONMENT_NAME $ENVIRONMENT_TYPE $BACKUP_TYPE Backup Starting" -excludeTimeStamp $true

    CreateSnapshotsForInstances $stagingInstanceIDs

    CleanupDailySnapshots

    WriteToLogAndEmail "$ENVIRONMENT_NAME $ENVIRONMENT_TYPE $BACK_UPTYPE Backup Complete" -excludeTimeStamp $true

    $end = Get-Date
    $timespan = New-TimeSpan $start $end
    $hours=$timespan.Hours
    $minutes=$timespan.Minutes
    WriteToEmail "Backup took $hours hr(s) and $minutes min(s)"

    WriteToEmail "Click here to test: $TEST_URL" -excludeTimeStamp $true
    SendStatusEmail -successString "SUCCESS"
}
catch
{
    SendStatusEmail -successString "FAILED"
}



WeeklySnapshot.ps1

[Download]

############## C O N F I G ##############
."C:\AWS\AWSConfig.ps1"

#Environment
$ENVIRONMENT_NAME = "My Environment"
$ENVIRONMENT_TYPE = "Development"
$BACKUP_TYPE = "Weekly"
$stagingInstanceIDs="i-xxxxxxxx","i-xxxxxxxx","i-xxxxxxxx"

############## F U N C T I O N S ##############
."C:\AWS\AWSUtilities.ps1"

############## M A I N ##############

try
{
    $start = Get-Date
    WriteToLogAndEmail "$ENVIRONMENT_NAME $ENVIRONMENT_TYPE $BACKUP_TYPE Backup Starting" -excludeTimeStamp $true

    StopInstances $stagingInstanceIDs
    CreateSnapshotsForInstances $stagingInstanceIDs
    StartInstances $stagingInstanceIDs

    CleanupWeeklySnapshots

    WriteToLogAndEmail "$ENVIRONMENT_NAME $ENVIRONMENT_TYPE $BACK_UPTYPE Backup Complete" -excludeTimeStamp $true

    $end = Get-Date
    $timespan = New-TimeSpan $start $end
    $hours=$timespan.Hours
    $minutes=$timespan.Minutes
    WriteToEmail "Backup took $hours hours and $minutes to complete"

    WriteToEmail "Click here to test: $TEST_URL" -excludeTimeStamp $true

    SendStatusEmail -successString "SUCCESS"
}
catch
{
    SendStatusEmail -successString "FAILED"
}



Configuration

Configure AWSConfig.ps1

Open AWSConfig.ps1:

  1. AWS Access Path
  2. Provide the Access Key ID,  Secret Access Key, and Account ID for your account. Get Account ID, Access Key and Secret Access Key from AWS: My Account / Console > Security Credentials
  3. Uncomment the the region that your instances are running in
  4. Choose a location to store logs
  5. Provide a from address (must be verified in Amazon Simple Email Services (SES))

Configure AWSUtilities.ps1

Open AWSUtilities.ps1 and execute the line:

New-EventLog -Source "AWS PowerShell Utilities" -LogName "Application

. This will allow the scripts to add entries into the event log.

Configure DailySnapshots.ps1 & WeeklySnapshots.ps1

Open both DailySnapshots.ps1 and WeeklySnapshots.ps1 and:

  1. Verify the paths to AWSConfig.ps1 and AWSUtilities.ps1
  2. Set the ENVIRONMENT_NAME to whatever you want to call the environment (ex. the name of the customer). This variable is used in notification emails.
  3. Set the ENVIRONMENT_TYPE to the name of the environment (ex. production, development, etc.)
  4. BACKUP_TYPE should be set to the name of the backup (i.e. daily or weekly); however, you can customize if you like.
  5. Set stagingInstanceIDs to the instances that make up your environment

Test it out

When you execute the DailySnapshot.ps1 script, the script will create a snapshot of each volume for each instance that you provided without shutting them down. Once it is complete, you should receive an email stating the status of the backup. Similarly, when you execute WeeklySnapshot.ps1, the script will shut down the instances, create snapshots of each volume on each instance, start them back up in the order listed, and then send you an email notification. You can see this in action if you review the AWS Disaster Recovery Demo.

Increase disk size for an EC2 instance in AWS

While using Amazon Web Services (AWS) you may find that, when using one of the Amazon Machine Images (AMIs) provided, you may run out of disk space. There does not appear to be any way to “resize” an Elastic Block Store (EBS) volume; however, you can create a new one based on an existing snapshot and replace the current drive with a larger one. I have provided the instructions for doing so below.

  1. Log into the AWS Management Console
  2. Make sure that the Instance that you wish to change is not currently running
  3. Navigate to Elastic Block Store > Volumes
  4. Check the box next to the Volume that needs more space
  5. Click the More… drop down list and select Create Snapshot
  6. Enter a Name and a Description
  7. Navigate to Elastic Block Store> Snapshots
  8. Monitor the progress of the Snapshot for completion
  9. Once complete, navigate back to Elastic Block Store > Volumes
  10. Click Create Volume
  11. Enter the desired size for the new volume
  12. Make sure that you select the same Availability Zone for your instance
  13. Select the Snapshot that you just created
  14. Click Yes, Create
  15. Monitor the progress of the Volume for completion
  16. Once complete, Check the box next to the Volume that is currently connected to the Instance
  17. Make sure that no other Volumes are selected
  18. Click the More… drop down list and select Click the More… drop down list and select Detach Volume
  19. Uncheck the box selected and check the box next to the new Volume
  20. Click the More… drop down list and select Click the More… drop down list and select Attach Volume
  21. Select the Instance that you wish to change
  22. Change the value in Device from xvdf  to /dev/sda1
  23. Click Yes, Attach
  24. Navigate to Instances and start your Instance
  25. Once you are satisfied that the volume works, feel free to delete the Snapshot and old Volume if you like

You will need to take additional steps to extend the size of your partition to use the rest of the allocated space. The process for doing so will vary depending on the operating system that you are using.

Using Powershell to export & import farm solutions

Here is a handy script that will export all farm solution .wsp and .cab files at once:

Add-PSSnapin Microsoft.SharePoint.PowerShell
$farm = Get-SPFarm
$farm.Solutions | ForEach-Object{$_.SolutionFile.SaveAs("c:\export\" + $_.SolutionFile.name)}</p>
Once you have moved the solutions to another machine, you can use the following script to add the solutions to the new farm:
<p style="padding-left: 30px;">Add-PSSnapin Microsoft.SharePoint.PowerShell
$files = Get-ChildItem "c:\install\"
ForEach ($file in $files) {Add-SPSolution $file.FullName}
